Specification

Model: PATTY100-V

Overall dimensions (LxWxH): 860mm x 600mm x 1400mm - Compact structure saves space in the workshop.

Meat Tank Capacity: 30L - Large capacity hopper reduces frequent refilling and ensures continuous production.

Working Air Pressure: 6 Bar (0.6 MPa) - Provides stable and powerful molding power.

Meat patty specifications:

Diameter range: 28mm - 120mm (customized molds available)

Thickness range: 8mm - 20mm (continuously adjustable)

Rated power: 0.55 KW - low energy consumption and economical operation.

Conveyor Belt Width: 130mm - Matches the size of the meat patties and conveys the finished products smoothly.

Weight: approx. 100 KG - Stable structure, smooth operation.

Theoretical output: approx. 35 pcs/min - Highly efficient output.

Product advantages:

Outstanding productivity: up to 35 pcs/min output rate, tens of times more efficient than manual molding, dramatically increasing production capacity and easily responding to batch orders.

Accurate size control: By changing the molds, a wide range of products can be produced from 28mm in diameter (small patties/meatball patties) to 120mm (large meat chops). Thickness can be finely adjusted continuously from 8mm (thin patties) to 20mm (thick chops), ensuring a high degree of consistency in product specifications and a uniform appearance.

Stable molding quality: 6 Bar stable air pressure drive, together with the precision molding mechanism, ensures that each patty is of uniform weight, moderate density and regular shape, which improves product quality and yield.

Convenient operation: Thickness adjustment mechanism is intuitive and easy to set without complicated tools. The large capacity 30L meat tank reduces the number of stops for refilling and increases the continuous operation time. The structure of the machine is designed for easy cleaning and maintenance.

Space and Energy Saving: Small footprint (860x600mm), suitable for all types of food processing plant layouts, low power 0.55KW motor, low running costs, energy saving and environmental protection.

Reliable Conveyor System: 130mm width food grade stainless steel mesh belt smoothly receives and conveys the formed patties to the next process (e.g. freezing, packaging or frying line entrance).
